Electrical
GPS Part:	Dielectric Antenna
Frequency Range	1575.42MHZ±3 MHz/1602-1610MHz
Polarization Type	RHCP
Gain	5dBi
V.S.W.R	<2.0
Impedance	50Ώ
LNA
LNA Gain	28±2dB Typical
Noise Figure	1.5dB
Ex-band Attenuation	12dB@CF+50MHz/16dB@CF-50MHz
V.S.W.R	＜2.0
Voltage	2.7/3.0/3.3/5.0/3.0 to 5.0 etc.
Current Consumption(mA)	11 Max
Impedance	50Ώ
DC current	5-15mA
WIFI Part:	Frequency range	2400-2500MHz
V.S.W.R	2.0:1
Gain	3dB
Polarization	Linear
Impedance	50Ω
LTE Part:	Frequency range	698-960MHz/1710-2700MHz
V.S.W.R	2.0:1
Gain	2dBi
Polarization	Linear
Impedance	50Ω
Mechanical
	Housing	Black
Cable	RG174
Length	3M
Connector	3xSMA Male
Environmental
	Working Temp	-40℃~+85℃
Humidity	55%-75%RH
Waterproof	IP67
Antenna Radome Material	ABS
Mount way	Screw
Antenna Dimension	Ф80×15 mm
Weight	150g
RoHS Compliant	YES
