1. Automatic feeding with adjuatable brackets
2. Speed is adjutable for different products
3. 75mm hole diamter for SKD11/DC53 thread rolling dies
4. Max. Rolling pressure is about 350KN
5. It is easy to operate and maintain the machine
6. CE, ISO9001-2008
Specification
Working diameter
12-90mm
Thread pitch
1.0-8mm
Thread length
In feed or Thru feed
Spindle speed
16/21/27/37/46/62rpm (variable speed)
Outside diameter of rolling die
170-220mm
Inside diameter of rolling die
75mm
Thickness of rolling die
180mm
Feed stroke
0-16mm
Total machine power
18KW
Max rolling pressure
35T
Supply voltage
380V 3P 50Hz
Weight(reference)
4080(KG)
Package Dimension(L*W*H)
1660*1780*1710mm
Dimension(L*W*H)
1600*1680*1650mm
